Description
WIRELESS DUAL-TECH DETECTOR
DS-PDD12P-EG2-WB AX PRO
HIKVISION 114-258
{tab Overview}
DS-PDD12P-EG2-WB WIRELESS DUAL-TECH DETECTOR
DS-PDD12P-EG2-WB is a fully supervised two-way wireless detector featuring motion and microwave detection, tamper protection, low battery and supervision.
It can operate for up to 5 years from two in-built batteies, and monitors the area within 12m radius, ingnores animals while recognizing human from the first step.
Features:
- 3D optics including creep-zone protection, full coverage without dead angle
- 24G microwave to prevent wall penetration
- Digital temperature compensation
- Fully remote configurable through App
- Multiple enrollment method and easy installation design
- Easy replaceable battery with PCB protected
- Frequency hopping against jamming for reliable transmission
{tab Specs}
| Detection Performance | |
| Detection Method | Passive Infrared,Microwave |
| Sensor Model | SFG321-711 |
| Detection Range | 12m |
| Detection Angle | 85.9° |
| Detection Zones | 52 |
| Detectable Speed | 0.3 to 2m/s |
| Sensitivity | Auto,High,Pet |
| Pet Immunity | 30Kg |
| White Light Filter | 6500lux |
| Microwave Frequency | 24GHz(24.15~ 24.25GHz) |
| Digital Temperature Compensation | Support |
| Creep Zone Protection | Support |
| Feature | |
| Digital Processing | Support |
| Sealed Optics | Support |
| Tamper Protection | Front,Rear |
| Environment Temperature Indicator | Support |
| Signal StrengthIndicator | Support |
| Interface | |
| Power Switch | Power Up Enrolling |
| LED Indicator | Green(PIR), Red(Microwave), Blue(Alarm) |
| Transmission | |
| Transmission Technology | Tri-X Wireless |
| Transmission Method | Two-Way RF Wireless |
| Transmission Frequency | 433MHz |
| Transmission Security | AES-128 Encryption |
| Transmission Range(Free Space) | 1.2Km |
| Frequency Hopping | Support |
| Enrolling Method | Power up,RemoteID,QR Code |
| Electrical Characteristics | |
| Standard Battery Life | 5 years in workstatus (being triggered 20 times per day) |
| Power Supply | Battery Powered |
| Battery Type | CR123A × 2 |
| Typical Voltage | 3V |
| General | |
| Operation Temperature | -10 °C to 55 °C(14 °F to 131 °F) |
| Storage Temperature | -20 °C to 60 °C(-4 °F to 140 °F) |
| Operation Humidity | 10% to 90% |
| Dimension(WxHxD) | 65.5mm × 103mm × 48.5mm |
{/tabs}
